Synchronous PCB board input system which runs with chain claw to ensure reliable, durable and no noise, stable transmission.
Technical Data Sheet
【Introduction】：
TB880C has a synchronal feeding system. Synchronal chain with claws design, no noise, smooth conveying. Control system: Industry computer with signal processing by hearing is reliable and stable. Far IR preheating system to prevent the temperature going down. New type boost spraying system of the welding flux reduces the dosage of the flux. Conveying system: imported motor for driving with overload protection device. The width of the substrate is adjusted automatically by computer.
【Remark】：
technology parameter of TB880C： Preheating Section (Infrared+ hot air): 3Kw * 2 Preheating temperature: Room-temperature -300 Preheating control mode: PID Mode Power of tin stove heating tube:6Kw * （1.5KW*2+3） Jointing control mode:PID Mode Wave crest motor: imported high temperature resistant motor Soldering tin capability：Max.500kg（Sn63Pb37）；430Kg（Sn100%） PCB width ： Max.250mm PCB Transmission speed： 0.5~1.8m/min Transmission motor power：90W Gross power：14Kw Working power： 18Kw Power supply : Three-phase,380V,50Hz Air supply： above 5Mpa Gas pressure of spray： 0.25Mpa~0.4Mpa Spray gun driving type: need a spraying machine outside Cooling system：wind cooling system. Dimension (L*W*H) 3400 *1200 *1500 Weight: about 1250kg
