Chemical tinning machine PCB350

Quantity:
This equipment is used to tin on the surface of PCB and enhance welding, at the same time it can protect PCB to not be etching.

 【Summary】:
 This equipment is used to tin on the surface of PCB and enhance welding, at the same time it can protect
 PCB to not be etching.

 【Process】:
 After electroplating and solidifying copper, put the copper board into tinning machine, there are 2 purposes:
 1. tin on the PCB and holes to finish plating PCB;2. enhance linking stably and welding effect after tinning.
 Steps:
 1 fix the board which has been electroplated and solidified, and then put it into tinning liquor, the pothook
 links rod of cathode.
 2 please adjust current according to size of board. The standard of current is : 2A/(dm)2, please calculate area of double side if it is double side board.
 3 take board out after 15 minutes.
 4 Please use liquor exit to let liquor out.
 5 Speed timing can adjust sway speed which is new design to control speed.

 Add: If the user had any special request, please arrange with us.

 【Technology parameters】:
 1、voltage range:DC0~8V
 2、current range:DC0~10A
 3、electroplating time:10-15 minutes. The time can be set according to your detail request.
 4、max capacity:490mm×290mm×350mm
 5、max power:350W
 6、dimension:620mm×310mm×490mm
 7、weight:45kg
