High-precision multi-function pick and place machine T8S

  T8 is one high-precision mounting machine that can mount 0201 and can mount 5 kinds of IC trays at one time.

IFrame
T8S Technology Parameters:

  T8 is one high-precision mounting machine that can mount 0201 and can mount 5 kinds of IC trays at one time.

  T8S, one amazing high-precision mounting machine!

  Selling point:

  2. World-class high-speed moving system, with original imported high-accuracy ball screw and high-precision rail, ensuring the machine keep high-precision and stability after long time use.

  3.The patented technology of non-stop scanning photos makes high-speed placement come ture.Maximum vision mounting speed up to 8000CPH.

  7.Configurable vibrable feeder, IC intelligent feeder, can pick and place 5 kind of QFP, BGA etc.

  8. Adopt the heads with proprietary technology, the speed of pick and place have been improved effectively. The actual  mount speed up to 6500-8000 cph
  T8 is one high-precision mounting machine that can mount 0201 and can mount 5 kinds of IC trays at one time.

  T8S, one amazing high-precision mounting machine!

  Selling point:

  2. World-class high-speed moving system, with original imported high-accuracy ball screw and high-precision rail, ensuring the machine keep high-precision and stability after long time use.

  3.The patented technology of non-stop scanning photos makes high-speed placement come ture.Maximum vision mounting speed up to 8000CPH.

  7.Configurable vibrable feeder, IC intelligent feeder, can pick and place 5 kind of QFP, BGA etc.

  8. Adopt the heads with proprietary technology, the speed of pick and place have been improved effectively. The actual  mount speed up to 6500-8000 cph

Mounter headr 4 Heads
Mounting Size 50mm×50mm430mm×250mm
Max Z Axis move range  30mm
Typical speed 6500-8000cph
Theoretical Max mount speed 10000cph
Moving System X axis moving coil motor + linear encoder
X.Y axis precision ±0.001mm
Repeat mount precision ±0.02mm
Position manner Visual Position
Component available Above 0201 below 30mm ICAbove 30MM is optional
Programme method Automatic data import/Video learning/Keyboard input
Feeder  8mm,12mm,16mm,24mm,32mm44mm GF feeders (Optional)
Feeder NO. 62 pieces of GF-08mm (maxmum)
IC tray No. TF-05 Electric intelligent IC charging wagon
Operation system WINDOWS XPWIN7
Compressed air 80psi0.5Mpagas flue≥100L/M
Power 380v50Hz7kw
Weight 980kg
Dimension 1450(L)×1100(W)×1440(H),
